IRS2092 500W+500W HiFi High Power Dual Channel Digital Class D Power Active Amplifier Board
Rs. 7,999.00
Availability: In Stock
SKU : iot-2092
Quick OverView
The circuit uses a high-power switching power supply to increase the power of the D-class amplifier integrated design. Through reasonable...
Qty:
-
The circuit uses a high-power switching power supply to increase the power of the D-class amplifier integrated design. Through reasonable layout and wiring, it ensures stable operation, outstanding sound quality, and easy use. The board design has a comprehensive protection circuit, including on/off delay protection to prevent impact noise. Overcurrent protection, high temperature protection, and cooling fan interface. Choose brand new high current MOS transistors and refuse to use disassembled transistors to ensure reliable quality.
Precaution:
- The circuit board is directly powered by 220V. When using it, it is necessary to follow the electrical specifications, install the circuit board in a fixed position, and there should be no metal objects touching the component feet at the bottom. Insulation pads need to be added. Do not touch the circuit board with your hands, and do not install the circuit board in a damp place with water.
- The circuit board uses XLR balanced input socket, and the output socket is SpeakON socket, supporting 4-core and 2-core SpeakON plugs.
Specification:
- Model: IRS2092
- Output channel: 2.0 channel
- Input interface: XLR
- Output interface: SpeakON
- Frequency response: 20Hz - 20kHz
- Power supply voltage: AC220V
- Standby power consumption: 22W
- Output power: 500W + 500W / 4ohms
- THD+N: 0.1%
- Protection mechanism: over-heat protection, over-current protection, power-on delay protection
- Product size: 210 x 139 x 35mm
Package Included:
- 1 x Power Amplifier Board
