IOT-Audios XY-T100L 100Wx2 APP Control Bluetooth 5.0 Subwoofer Amplifier Board High Power Audio Stereo Amplifier Board AUX USB Bass Treble

Rs. 1,499.00

Availability: In Stock

SKU : XY-T100L

Quick OverView
XY-T100L 100Wx2 APP Control HiFi Audio Amplifier Bluetooth-Compatible 5.0+AUX+Sound Card+Flash Disk Digital Amplifier Board Dual Channel Stereo Wireless Speaker ModuleFeature:
XY-T100L 100Wx2 APP Control HiFi Audio Amplifier Bluetooth-Compatible 5.0+AUX+Sound Card+Flash Disk Digital Amplifier Board Dual Channel Stereo Wireless Speaker Module
Feature:
1. Adopt domestic Class-D Power amplifier chip scheme: high efficiency, good distortion and anti squeak; Transparent sound quality and strong driving force
2. Bluetooth-compatible 5.0 audio power amplifier module: 2.0 dual channel stereo output, maximum output power 2x100W, with front stage high and low bass adjustment; Pure HiFi 2.0 fever sound quality. The treble is pure and transparent, the midrange is gentle and delicate, and the bass is surging and shocking.
3. Classic appearance multifunctional main knob: the main knob adopts rotary encoder only used in high-end power amplifier to realize 360 degree stepless tuning. It feels smooth, one key start and stop, long press to start and stop, and the operation is simple and convenient.
4. Support mobile app control: app visual operation playback mode, support for Apple /Android (please download for Google market and search 'sinilink' for download).
5. Supported audio input: Bluetooth-compatible 5.0, aux, USB sound card, USB flash disk (the USB flash disk file system must be fat 32, and the maximum support is 32GB)
6. Supported audio output: active speaker and passive speaker (Note: only one of passive speaker and active speaker can be selected)
7. Support USB flash disk playback: insert USB flash disk, open app, switch to "USB flash disk" mode, accompanied by prompt tone, and enter USB flash disk playback mode
8. Support the computer sound card function: it can output signals with better sound quality than the computer, connect the speaker to play, connect the Bluetooth-compatible board card to the computer with the data cable, open the app, click the switch "sound card" to complete the switch and play with a prompt sound. Open the computer playback software and play music
9. Heat dissipation mechanism: a large-area heat sink pasted with special heat conducting silica gel is adopted, and the copper coating close to the shell is used for heat dissipation. The heat dissipation area is doubled to ensure the full power and high-performance operation of the product.

Specification:
Model: XY-T100L
Power supply: above DC 5-24v / 10A
Bluetooth-compatible version: 5.0
Audio input: Bluetooth-compatible + aux + USB flash disk + USB sound card
Audio output: passive speaker + 3.5mm interface stereo output
Volume adjustment: high-end encoder knob adjustment, smooth feel
Frequency range: 20hz-30khz
Signal to noise ratio: 92dB
Adaptive horn: 20w-200w / 4 Ω - 8 Ω
Output power: 100W * 2
Unique function: support sinilink app control
Protection mechanism: electrostatic protection, overheating protection, overcurrent protection and short circuit protection
Size: 93 * 65 * 25MM/3.7X2.6X0.98in
Weight: 107g

Heat sink installation:
During assembly, pay attention to the installation of the heat sink. After the heat sink silicone is adhered to the heat sink, stick the silicone side of the heat sink to the power amplifier chip; Note that the metal shell of the heat sink must not be in contact with the surrounding components to avoid short circuit; Finally, press the top plate against the heat sink to dissipate heat through the top plate to achieve better heat dissipation effect.

Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
